Suitable for HP air, hot water, HP water and water based slurry delifery applications.
|
ID
|
OD
|
WEIGHT
|
|
|---|---|---|---|
|
inch
|
mm
|
mm
|
kg/metre
|
|
3/8
|
10
|
22
|
0.4
|
|
1/2
|
13
|
25
|
0.5
|
|
3/4
|
20
|
33
|
0.7
|
|
1
|
25
|
38
|
1
|
|
1 1/4
|
32
|
48
|
1.5
|
|
1 1/2
|
38
|
55
|
1.9
|
|
1 3/4
|
44
|
61
|
2.2
|
|
2
|
51
|
68
|
2.4
|
|
2 1/4
|
57
|
74
|
2.8
|
|
2 1/2
|
63
|
80
|
3.2
|
|
2 3/4
|
70
|
89
|
3.6
|
|
3
|
76
|
96
|
4
|
|
3 1/2
|
88
|
108
|
4.5
|
|
4
|
102
|
122
|
5.2
|
|
4 1/2
|
115
|
135
|
5.6
|
|
5
|
128
|
150
|
6.1
|
|
5 1/2
|
140
|
162
|
6.7
|
|
6
|
153
|
175
|
7.4
|
Product Specifications
WORKING PRESSURE
- 17 Bar (250 Psi)
TUBE
- Black oil mist resistant synthetic rubber
REINFORCEMENT
- Layers of high strength textile yarn / cord
COVER
- Black, weather, and abrasion resistant synthetic rubber
IDENTIFICATION
- Yellow Longitudinal stripe SUPERHOSE Heavy Duty Air. Type-2002 WP 250 Psi
LENGTH
- Available in 20 and 40 metres as standard, other length & diameter on request
FACTOR OF SAFETY
- 1:3
