Suitable for fuel, oil, air and water delivery applications.
|
ID
|
OD
|
WEIGHT
|
|
|---|---|---|---|
|
inch
|
mm
|
mm
|
kg/metre
|
|
1/2
|
13
|
26
|
0.5
|
|
3/4
|
20
|
33
|
0.9
|
|
1
|
25
|
38
|
1.1
|
|
1 1/4
|
32
|
48
|
1.6
|
|
1 1/2
|
38
|
55
|
1.9
|
|
1 3/4
|
44
|
61
|
2.1
|
|
2
|
51
|
69
|
2.4
|
|
2 1/4
|
57
|
75
|
2.6
|
|
2 1/2
|
63
|
81
|
2.8
|
|
2 3/4
|
70
|
88
|
3
|
|
3
|
76
|
95
|
3.4
|
|
3 1/2
|
88
|
105
|
3.8
|
|
4
|
102
|
120
|
4.3
|
|
4 1/2
|
115
|
135
|
4.8
|
|
5
|
128
|
148
|
5.3
|
|
6
|
153
|
173
|
6.3
|
Product Specifications
WORKING PRESSURE
- 10 Bar (150 Psi)
TUBE
- Black oil and fuel resistant Nitrile rubber
REINFORCEMENT
- Layers of high strength textile yarn / cord & one anti static wire
COVER
- Black oil, weather & ozone resistant Cloroprene rubber
IDENTIFICATION
- Red Longitudinal stripe SUPERFLEXHOSE Oil delivery. Type - 3002 WP 150 Psi
LENGTH
- Available in 20 and 40 metres as standard, other length & diameter on request
FACTOR OF SAFETY
- 1:3
